Everything You Need to Know about Package on Package Assembly
Libby Foster • February 21, 2023

In modern electronics manufacturing, a wide variety of components are used to create complex devices. One innovation that has been developed to improve the performance and capabilities of these devices is the Package on Package (PoP) assembly. PoP involves stacking two or more packages, such as memory and processor packages, on top of each other. This approach offers several benefits and has become increasingly popular in the electronics industry.

package on package assembly

What is Package on Package Assembly?

The package on Package (PoP) is a type of assembly process that involves stacking two or more packages vertically on top of each other. This method enables the stacking and interconnection of various components to make a single, compact module. This configuration is similar to a multilayer printed circuit board (PCB), but with the added benefit of lowering the device's total size and height.


A PoP typically consists of a bottom package containing a processor, microcontroller, or ASIC and a top package containing memory such as DRAM, flash, or SRAM. The bottom package is typically soldered to the PCB, whereas the top package is typically adhered to the bottom package by an interposer or adhesive.


Advantages of PoP Assembly

PoP offers several advantages over traditional package assembly methods, such as single in-line packages (SIP) and single inline memory modules (SIMM).


  1. Reduced Size:
    PoP assemblies are much smaller in size compared to other traditional assembly methods. Since the top package is stacked on the bottom package, there is no need for additional PCB space to accommodate memory components. The result is a much smaller form factor, which is ideal for devices with limited space.
  2. Improved Performance: PoP allows for better communication between different components as it reduces the distance between them. The shorter distance between the memory and processor components reduces the time required for data transmission, which improves the device's overall performance.
  3. Increased Memory Capacity: Since PoP allows for stacking multiple memory packages, it can significantly increase the memory capacity of a device. This feature is especially useful for high-end devices that require large amounts of memory.
  4. Improved Reliability: PoP assemblies offer better reliability compared to other package assembly methods. Since the components are stacked vertically, they are less susceptible to mechanical stress and are more resistant to thermal cycling.
  5. Simplified Manufacturing: PoP assembly simplifies the manufacturing process, as it eliminates the need for additional PCB space to accommodate memory components. This approach reduces the number of components that need to be assembled, resulting in faster and more efficient production.

Applications of PoP Assembly

PoP assemblies are found in a variety of applications such as mobile devices, game consoles, networking equipment, and medical devices. PoP assemblies are used in mobile devices such as smartphones and tablets to stack memory components and processors, resulting in high-performance devices with a tiny form factor.


PoP is utilised in gaming consoles to stack numerous memory components, resulting in high-speed data transfer rates and increased game performance. PoP assemblies are used in networking equipment to stack numerous memory and processor components, resulting in high-speed data transfer and better network performance.


Conclusion

The package on Package assembly is a novel way of electronics manufacturing that provides for higher memory capacity, decreased size, and improved performance. PoP assemblies have grown in popularity in the electronics sector because they provide various advantages over traditional assembling methods. PoP assembly is predicted to become increasingly more common in the future as demand for high-performance devices with compact form factors grows.
